Modern Prefab Portable Detachable Container House 20ft Modular Prefab Detachable Container Dubai

1.0 Units
MOQ
Modern Prefab Portable Detachable Container House 20ft Modular Prefab Detachable Container Dubai
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Year
After-sale Service: Online Technical Support, Onsite Installation
Project Solution Capability: Graphic Design, 3D Model Design
Application: Warehouse
Model Number: Detachable Container
Use: Hotel, House, Office, Sentry Box,Guard House, Shop
Product Type: Container Houses
Design Style: Modern
Color: Customized Color
Window: Aluminum Window
Certification: CE Certification
Floor: MGO Board
Wall: EPS Sandwich Panels
Roof: EPS Sandwich Panels
Accessories: Screw Blot, Nail
Electrical Device: Switch,Light,Socket Etc.
Door: Steel Door
Standard Size: 5950*2400*2870mm Or Customized
Basic Infomation
Certification: CE Certification
Model Number: Detachable Container
Payment & Shipping Terms
Supply Ability: 1000 Unit/Units per Month
Product Description

Product Description

Detachable Container standard size is 3mX6mX2.88m, it evolved on the basis of export-type container houses, after optimizing the material of container house, suitable for the construction site in China, it is the first choice of mobile housing on construction site. Its advantages are convenient on transportation and installation, beautiful appearance, generous, max stack 3 floors, excellent seismic performance.

Quotation list of Detachable container house
No. Component Specification Unit Quantity Remarks
1 Column 2480*2.3 Strip 4 High of Beam:195MM
Sink:65MM
Thickness:2.3MM Hot-dip Galvanized Sheet Profile
2 Bottom Beam 5630*2.3 Strip 2
3 Bottom Beam 2680*2.3 Strip 2
4 Top Beam 5630*2.3 Strip 2
5 Top Beam 2680*2.3 Strip 2
6 Corner Piece 195*165*4 Piece 8
7 Top Platen Slot 5730*1.2 Strip 2 Galvanized
8 Top Platen Slot 2790*1.2 Strip 2
9 Corner Fitting 120*1.2*2530 Strip 1
10 Bottom Beam SquareTube 100*50*2980*1.3 Strip 9 Galvanized
11 Top Beam SquareTube 50*50*2800*1.8 Strip 2 Galvanized, with Card Slots On Both Sides
12 Top Beam SquareTube 80*40*1880*1.5 Strip 3 Galvanized
13 Top Beam Square Tube 60*40**1880*1.5 Strip 6
14 Main Frame Bolt ST100*30 Piece 64 Carriage Bolt
15 Bottom Beam Bolt ST100*80 Piece 18
16 Floor 2800*1146*18 Sheet 5 MGO Fireproof Board
17 Structural Adhesive   Piece 5
18 Ceiling Board 2788*200*0.3 Piece 29
19 Roof Tile 2920*950*0.5 Piece 6
20 Roll Felt 20M Roll 1
21 Hardware   Carton 1
22 Butyl Rubber Strip   M 12
23 Corner Fitting 38 Strip 2
24 Door 925*2050 Piece 1
25 Window 925*1200 Piece 2
26 Board Material 2560*950*50 Piece 15 0.276Glass Wool Board
27 Board Material 1380*950*50 Piece 2 0.276Glass Wool Board
28 Board Material 460*950*50 Piece 1 0.276Glass Wool Board





Advantage

1. Perfect for modular / prefab site offices, cabins, warehouse, villa, toliet, shop, hotel, camp, office.
2. Efficient, low cost designs that can be customized for end user requirements.
3. Easy for low skilled workers to assemble.
4. The light steel frame structure is strong and reliable.
5. Many modular units can be stacked and linked together to create more space.



Flexible Combination
The container house can be linked freely at length, width and height through the linking kits for bigger structure and different layout.



Fast Installation
The standard house can be packed in one package for quick material collection, and four workers can erect 5unit per day.



Flat Package
The standard house can be packed in one package, including roof structure, floor, wall panels, doors, windows and interior decoration.

Applications
Contact Us

Detachable Container Detachable Container Detachable Container Detachable Container Detachable Container

Company Information

Guangdong Cbox Co., Limited. which covers 350,000 square meters and has an annual output of 200,000 containers, focus on designing and developing, producing, selling, installing, operating, and serving as a whole, providing one-stop box rental and manufacturing for customers.

C.Box covers a series of products such as steel structure workshops, flat pack container house , modified shipping container house, detachable container house, folding container house, expandable container house, portable toilets, prefabricated house,light steel villas, swimming pools, etc., we provide customers with design, production, installation, Services and other one-stop solutions.

After 15 years of hard work by the company's core team, it has obtained 46 invention patents and utility model patents.

We take the need of customer as the base, green safe, economical and comfortable living experience as the root and development of the industry as the purpose.

Packaging & Shipping

FAQ

1.Are you a factory or trading company?
Guangdong Cbox Co., Limited. is a factory located in Shunde district, Foshan, Guangdong province, China.

2.What's your delivery time?
Normal order delivery time is 2-30 days after receive deposit.
Big order delivery time should confirm with order management dept.

3.What is your terms of payment ?
30% deposit in advance, balance before shipment.

4.Is it difficult to build a prefab house?
Easy to install, installation video and guide book send to you showing how to fast installation.
Or we can send engineer or installation team to construction site.

5. Do you provide on-site installation service?
Big projects provide installation services, Installation charge standard: 150USD/day, customer charge travel fee, accommodation, translation fee, and ensure staff’s health and safety.

6. How do you guarantee the quality of the products?
Quality first, 100% Strict quality checking before delivery.

7.How can I get the quotation of the project ?
If you have drawing, we can offer quotation accordingly.
If you don't have design, we will design some drawings for your confirmation, and then offer quotation.

8.What is your supply capacity?
We supply over 160000 sets standard container house monthly.

9.Can help to purchase the appliances and install inside?
We can help purchase some appliances if needed such as air conditioning, refrigerator, dishwasher, oven etc, packed inside container ship together with container house.

10. How to get a fast quotation?
You tell us container house type, size, quantity, material of roof, wall, floor and other parts, we will check and fast offer you quotation. For the detachable container house and portable toilet, we can give you the price within 10 minutes after receive your specifications.
