Modern Log Cabin Kits Prefab Modular Heat Insulation Flat Pack Collapsible Container Accommodation Houses China

1 Acre
MOQ
$1,950.00(1 - 4 acres) $1,949.00(5 - 9 acres) $1,948.00(>=10 acres)
Price
Modern Log Cabin Kits Prefab Modular Heat Insulation Flat Pack Collapsible Container Accommodation Houses China
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Year
After-sale Service: Online Technical Support, Onsite Installation, Onsite Training
Project Solution Capability: Graphic Design, 3D Model Design, Total Solution For Projects
Application: Apartment, School, Workshop, Dormitory, Living Room
Place Of Origin: Sichuan, China
Brand Name: EVST
Model Number: EVST-Folding, EVST-Flat Pack, EVST-Detachable
Use: Hotel, Office, Shop
Product Type: Container Houses
Design Style: Modern
Product Name: Prefab Container House
Keyword: Prefab Houses Modern
Main Structure: Profile Steel
Window: One Or Two
Type: Flat Pack Modular House
Installation: Professional Guide
Color: White Or Customized Color
Basic Infomation
Place of Origin: Sichuan, China
Brand Name: EVST
Model Number: EVST-Folding, EVST-Flat Pack, EVST-Detachable
Payment & Shipping Terms
Packaging Details: Container
Supply Ability: 50000 Acre/Acres per Month
Product Description
Products Description
Thermal Insulation Log Cabin Kits Prefab Modular Flat Pack Folding Foldable Container Housing Houses China

EVST is a professional container house provider, we focus on designing, manufacturing, marketing. We can supply folding houses, flat pack houses, detachable houses with quick production and fast delivery. Our container houses are widely applied in temporary dormitories, temporary reception centers, commercial temporary offices, real estate exhibition halls, product exhibition halls, shops, etc. With 20 years’ experience, advanced manufacturing equipment, strict quality controlling, we can support you with one-stop solution for any of your requirements on container house.
Application Scenario

Container house is a movable and reusable building product, also called "box house" or "prefab house", it can be put into use very conveniently and efficiently because of modular design and factory production. A container is a basic unit, it can be used alone, or it can form a spacious use space through different combinations of horizontal and vertical directions. The container house unit structure is a standard component with special section steel connected by bolts, the container house wallboard and sideboard are made of rock wool board or glass wool board covered with colored steel. With the advantages of quick installation and reusable features, it can be used in temporary dormitories, real estate exhibition halls, product exhibition halls, temporary reception centers, commercial temporary offices, shops, etc.
Product Paramenters


Flat Pack Container House Parameters

Specification
length*width*height(mm)
6055*2990*2900(inner:5845*2780*2540)
Roof
Flat roof, organized internal drainage through
4 columns (drain section 40mm*80mm)
layer
≤3
Design Parameter
structural design service life
20 years
floor live load
2.0KN/㎡
roof live load
0.5KN/㎡
wind load
0.6KN/㎡
seismic fortification intensity
8 degree
Structure
corner column
specification:210*150mm,galvanized cold
rolled section steel,t=3.0mm,texture: SGC440
roof girder
specification:170mm,compressible stiffeners
,galvanized cold rolled section steel,t=3.0mm
,texture:SGC440
ground girder
specification:160mm,compressible stiffeners
,galvanized cold rolled section steel,t=3.0mm
,texture:SGC440
roof secondary girder
specification:C80*40mm,cold-formed
thin-walled c steel,t=1.0mm,texture:Q235B
ground secondary girder
specification:100*50mm,galvanized square
pipe,t=1.0mm,texture:Q235B
drain slope
specification:30*30mm,galvanized square
pipe,t=1.0mm,texture:Q235B
surface coating
specification:25*25mm,galvanized square
 pipe,t=1.0mm,texture:Q235B
surface coating
white powder electrostatic spraying, paint
 surface≥80μ
Roof
roof board
0.45mm Aluminized zinc color steel plate,
white gray color
thermal insulation
75mm glass wool insulation, bulk
density ≤14㎏/m³, combustion level is Class
A non-combustible
ceiling board
W-837 type, 0.4mm aluminum-zinc color-coated
 sheet pressure type, hidden nails,
white-gray color
Ground
decorative board
1.6mm vinyl floor
flashing groove
75 integrated flashing groove
Door
base
18mm calcium silicate board,
2810*1176mm, density:1.2g/cm²
Wall
wall board
950 type 75mm color steel sandwich panel,
outer 0.4mm orange peel, inner 0.4mm orange
peel, PE coating color white gray
Window
thermal insulation
75mm rock wool, bulk density 50㎏/m³,
combustion performance is Class A
non-combustible
Door
specification (mm)
width 930*height 2070mm
texture
steel door, with frame, European standard
fireproof lock door
Window
specification (mm)
width 930*height 1100mm
frame texture
Plastic steel, auxiliary frame-anti-theft rod,
screen window
glass
4mm+9mm+4mm Double insulating glass
Electricity
voltage
220v~250v
wire
Home main power cord 6.0*3, air conditioner
cord 4.0*3, socket cord 2.5*3, lighting switch
cord 1.5*2
circuit breaker
High section miniature circuit breaker,
(Chint brand)
lighting
2 groups of led strip lights, 24W
socket
3 five-hole sockets 10A, 1 three-hole socket 16A,
 1 single switch 10A, (midea brand)
Skirting line
pvc texture, hidden nails, white-gray color


Folding Container House Parameters


Detachable Container House Parameters

Installation Steps

Container house as a prefab house, the biggest advantage is its installation convenience, so it is very easy for any one to install, we have made detailed installation process instructions for you to view.
